Model No: SX25-FZ86C-28L, SX25-FZ86C-50L, SX25-FZ86C-58L, SX25-FZ86C-108L
Technical Parameters:
| Model |
SX25-FZ86C-28L |
SX25-FZ86C-50L |
SX25-FZ86C-58L |
SX25-FZ86C-108L |
| External Size(W*D*H)mm |
505*520*1165 |
660*715*1165 |
635*757*1212 |
700*730*1260 |
| Internal Size(W*D*H)mm |
266*281*400 |
360*456*395 |
330*453*410 |
460*460*510 |
| Capacity |
28L |
50L |
58L |
108L |
| Type |
Vertical |
| Temp. Range |
-40℃~-86℃ |
| Temp.Accuracy |
0.1℃ |
| Control System |
Microprocessor control, 7-inch LCD touch screen |
| Alarm |
High and low
temperature alarm,
sensor failure alarm |
High and low
temperature alarm,
power fault alarm,
thermostat fault
alarm |
High and low
temperature alarm,
sensor failure alarm,
thermostat failure
alarm power failure
alarm, door open alarm,
ambient temperature
alarm, condenser failure
alarm, filter inspection
alarm, abnormal voltage
alarm, low battery alarm |
High and low
temperature alarm,
sensor failure alarm |
| Alarm Method |
Sound beeps and lights flash |
| Refrigeration Type |
Direct refrigeration |
| Refrigerant |
R404a, R23 |
R600a 85g, R290 15g, R1150 27g, R14 20g |
R290, R170 |
R404a, R23 |
| Compressor |
1pc |
| Construction |
Foam Layer
Thickness |
100mm |
130mm |
150mm |
120mm |
Internal
Material |
304 stainless steel |
Extemal
Material |
Sprayed steel plate |
| Chamber with Inner Door |
1 |
1 |
1 |
2 |
| Shelf |
1 |
1 |
1 |
2 |
| Temp. Test Port |
1pc, dia. 18mm |
1pc, dia. 30mm |
1pc, dia. 25mm |
1pc, dia. 18mm |
| Consumption |
390W/1170VA |
540W/550VA |
442W/400VA |
520W/1560VA |
| Power Supply |
AC110V/220V±10%, 50/60Hz |
AC110~220V, 50/60Hz |
AC110V/220V±10%, 50/60Hz |
AC110V/220V±10%, 50/60Hz |
| Standard Accessory |
/ |
/ |
USB port |
/ |
| Optional Accessory |
USB port |
USB port |
Printer |
USB port |
| Package Size(W*D*H)mm |
580*600*1325 |
765*825*1350 |
730*845*1400 |
785*800*1430 |
| Gross Weight(kg) |
85 |
134 |
155 |
133 |
