Model No: SX25-CAA1200
Features:
150 sample positions
160 reaction cuvettes
180 refrigerated reagent positions
Optical filter/fiber bragg grating selectable
800 tests per hour (1200 tests with ISE module)
Built-in sample barcode system (optional)
Probe with anti-collision function, liquid level detection function
Technical Parameters:
| Specification | Details |
|---|---|
| Model | SX25-CAA1200 |
| Overall Performance | |
| Throughput | 800 tests/hour, 1200 tests/hour with ISE (Optional) |
| Analysis Method | End-point, Fixed-time, Rate (Kinetic), Turbidimetry |
| Certificates | CE, FDA, ISO9001, ISO13485 |
| Sample & Reagent System | |
| Sample Positions | 150 sample positions |
| Reagent Positions | 180 reagent positions |
| Sample Volume | 1~70μl |
| Reagent Volume | 10~350μl |
| Probe | Teflon coating, with anti-collision function, Liquid level detection function |
| Probe Washing | Automatic washing interior and exterior |
| Reagent Cooling | Refrigerated tray with independent switch |
| Reaction System | |
| Temperature Control | Water bath 37±0.1℃, real-time monitoring |
| Cuvettes | 160 reusable cuvettes, optical length 6mm |
| Mixer Probe | Independent stirring |
| Washing | Automatic cuvettes washing |
| STAT Function | Yes |
| Optical System | |
| Light Source | 12V/20W halogen lamp/fiber bragg grating optional |
| Spectrophotometry | Post-spectral spectrophotometry |
| Wavelength | 12 wavelengths from 340~800nm |
| Absorbance | 0~3.5Abs |
| Calibration & QC | |
| Calibration | Linear: K factor, 1-point, 2-point, and multipoint linear Non-Linear: Spline, Polygon, Logit-4P, Logit-5P |
| Quality Control | Real-time QC, Westgard Multi-Rule, Cumulative Sum Check, Twin Plot (2D), Daily QC, Monthly QC |
| Data Management | |
| Software | Windows 7/8/10, 32 or 64 bit |
| LIS System | Bi-directional, supports HL7 protocol |
| Interface | LAN port access |
| Printer | External optional, multiple reporting modes available |
| Working Conditions | |
| Power Supply | AC220V±10%, 50/60Hz; 110V±10%, 60Hz, 1500W |
| Temperature | 15~30℃ (±2℃) |
| Water Consumption | Deionized water: <25L/H |
| Humidity | 40%~85% |
| Size & Weight | |
| External Size (WDH) | 13607951155mm |
| Net Weight | 290kg |
| Package Size (WDH) | 17299691435mm |
| Gross Weight | 400kg |
