Model No: SX25-BBR-4V86, SX25-BBR-4V136, SX25-BBR-4V296, SX25-BBR-4V356, SX25-BBR-4V466
Features:
-
Multiple Sensors Design: Ensures precise monitoring and programming for optimal performance.
-
Unibody Design: Mono-assembly foaming with rigid polyurethane insulation material for enhanced durability and efficiency.
-
Forced Air Refrigeration System: Guarantees consistent and uniform temperature control within the unit.
-
Adjustable Shelves: Maximizes space utilization, with blood storage baskets that allow for classified organization.
-
Individual Transparent Inner Door: Effectively reduces cool air loss when opening the door, maintaining internal temperature stability.
Technical Parameters:
| Model |
SX25-BBR-4V86 |
SX25-BBR-4V136 |
SX25-BBR-4V296 |
SX25-BBR-4V356 |
SX25-BBR-4V466 |
| Capacity |
86L |
136L |
296L |
356L |
466L |
| Temp. Range |
4±2℃ |
| Temp. Accuracy |
0.1'℃ |
| Control System |
Microprocessor control |
| Display |
LED display |
| Alarm |
Audio and visual alarm for: High or low temperature, Sensor&system failure, Door ajar, Power failure |
| Refrigeration Type |
Forced air refrigeration system |
| Refrigerant |
R134a, CFC-Free |
| Compressor |
International famous compressor |
| Condenser&Evaporator |
High efficiency air-cooled condenser; Made of copper |
| Defrost |
Frost less design |
| Construction |
Uni body Design, Mono-assembly foaming(Rigid polyurethane insulation material) |
| Material |
Internal Material |
Stainless steel |
| External Material |
Sprayed steel plate |
| Door |
Electric heated glass
semi-foamed door with lock;
Acrylic inner door |
Electric heating glass outer door;
Acrylic inner door;
Outer door with locking buckle |
Electric heated glass semi-foamed door with lock; Acrylic inner door |
| Consumption |
245W/264VA |
252W/264VA |
267W/528VA |
352W/528VA |
380W/594VA |
| Power Supply |
Standard: AC220V±10%, 50Hz
Optional: AC110/220V, 60Hz |
Standard: AC220V±10%, 50Hz |
| Casters |
Two universal casters with brakes, two directional casters |
| Adjustable Shelves |
2pcs |
4pcs |
4pcs |
5pcs |
5pcs |
| Baskets |
6pcs |
12pcs |
12pcs |
15pcs |
20pcs |
| Blood Bags(450ml) |
66pcs(450ml) |
132pcs(450ml) |
156pcs(450ml) |
195pcs(450ml) |
300pcs(450ml) |
| Standard Accessory |
Thermal printer, LED lamp, The temperature test box, probe access port, door key |
| Optional Accessory |
Temperature recorder, USB port, RS485, Increase shelves number |
| External Size(W*D*H)mm |
530*660*1037 |
530*660*1287 |
630*720*1658 |
630*720*1886 |
680*747*1886 |
| Package Size(W*D*H)mm |
680*740*1330 |
685*750*1560 |
780*840*1910 |
770*830*2070 |
820*910*2080 |
| Gross Weight(kg) |
103 |
120 |
160 |
175 |
199 |
