Model No: SX25-D1100FH, SX25-D1200FH, SX25-D1300FH, SX25-D1500FH, SX25-D1800FH
Features:
-
The cabinet is designed with a vertical surface, providing a wide and more humanized operation perspective.
-
Made of high-quality cold-rolled steel plate material, with surface electrostatic spraying for a good finish.
-
The platform panel of the operation area is made of solid physical and chemical plate, resistant to acid and alkali corrosion, and can be disassembled for easy cleaning (integral type).
-
The front window is made of 5mm thick tempered glass, offering better protection for personnel and experiments.
-
Counterweight manual front window, height adjustable.
-
The base bracket and fume caster are integrated, allowing for safe movement through casters, while also ensuring it is well fixed and leveled.
-
Equipped with a PP axial flow fan, providing a large air volume, low noise, long service life, and easy installation.
-
The fan offers stepless speed regulation, with a push-button switch for stable performance.
-
The side of the cabinet body is equipped with lifting handles for easy carrying.
Technical Parameters
| Specification | Details |
|---|---|
| Model | SX25-D1100FH, SX25-D1200FH, SX25-D1300FH, SX25-D1500FH, SX25-D1800FH |
| Number of Users | Single, 1 |
| Rated Power | 125W (Not including socket load power, load power cannot exceed 500W) |
| Power Supply | 220V±10%, 50Hz (Standard); 110V±10%, 60Hz (Optional) |
| Exhaust Volume | 1850m³/h |
| Air Velocity | 0.3m/s~0.8 m/s |
| Noise | ≤65dB(A) |
| LED Lamp | 12W, 16W |
| Max Opening | 490mm (Integral Type) |
| Tabletop Height | 810mm (Integral Type) |
| Standard Accessory | LED lamp, National standard three-core splash-proof socket |
| Net Weight | |
| Desktop Type | 85kg, 89kg, 93kg, 102kg, 114kg |
| Integral Type | 126kg, 132kg, 138kg, 151kg, 170kg |
| External Size (WDH) | |
| Desktop Type | 11008001260mm, 12008001260mm, 13008001260mm, 15008001260mm, 18008001260mm |
| Integral Type | 11008002060mm, 12008002060mm, 13008002060mm, 15008002060mm, 18008002060mm |
| Internal Size (WDH) | 980660847mm, 1080660847mm, 1180660847mm, 1380660847mm, 1680660847mm |
| Package Size (WDH) | |
| Desktop Type | 12409551420mm, 13409551420mm, 14409551420mm, 16609751485mm, 19609751485mm |
| Integral Type | 124011101420mm, 134011101420mm, 144011101420mm, 166011301485mm, 196011301485mm |
| Gross Weight | |
| Desktop Type | 110kg, 116kg, 123kg, 182kg, 204kg |
| Integral Type | 153kg, 161kg, 170kg, 234kg, 263kg |
