Pilot Freeze Dryer SX25-PFD20S, SX25-PFD20T, SX25-PFD30S, SX25-PFD30T

Model No: SX25-PFD20S, SX25-PFD20T, SX25-PFD30S, SX25-PFD30T

Here is the cleaned-up version of your features:

Features:

Pre-freezing and in-situ drying for easy operation and effective drying results.
Inflatable discharge valve with a safety diaphragm, capable of connecting to an inert gas source to extend the shelf life of materials.
Freeze-drying curve optimization control technology, allowing control over the cooling rate during pre-freezing, as well as the heating rate and vacuum value during sublimation and analytical drying stages.
10-inch true color touch screen.
Ability to save hundreds of process recipes, with each group containing 50 temperature control sections to improve process optimization.
Intelligent data recording system that records and displays cold trap temperature, sample temperature, and vacuum degree curves in real-time. Exported data can be viewed and printed on a computer to facilitate process optimization and drying effect verification.
Flexible manual and automatic control modes; manual mode for process trial and automatic mode for batch production.
Real-time alarm display and historical alarm query function for fault diagnosis and equipment maintenance.
User-level and password settings for decentralized operation management.

Technical Parameters:

Model	SX25-PFD20S	SX25-PFD20T	SX25-PFD30S	SX25-PFD30T
Type	Standard	Stoppering	Standard	Stoppering
Freeze Drying Area	0.3m²	0.2m²	0.4m²	0.3m²
Shelf Temperature	-55℃～+70℃ (no-loading)	-55℃～+70℃ (no-loading)	-55℃～+70℃ (no-loading)	-55℃～+70℃ (no-loading)
Cold Trap Temperature	<-80℃ (no-loading)	<-80℃ (no-loading)	<-80℃ (no-loading)	<-80℃ (no-loading)
Vacuum Degree	≤1Pa (no-loading)	≤1Pa (no-loading)	≤1Pa (no-loading)	≤1Pa (no-loading)
Water Capture Capacity	≥6kg/24h	≥8kg/24h	≥6kg/24h	≥8kg/24h
Cold Trap Volume	15L	20L	15L	20L
*Cold Trap Size (DiameterH)**	Φ200*450mm	Φ220*520mm	Φ200*450mm	Φ220*520mm
Drying Chamber Size (WDH)	330320470mm	420320490mm	400350430mm	380380540mm
Shelf Size (WDH)	40027020mm	34030020mm	40027020mm	34030020mm
Qty. of Shelf & Tray	Shelf: 3+1, Tray: 3	Shelf: 2+1, Tray: 2	Shelf: 4+1, Tray: 4	Shelf: 3+1, Tray: 3
Sample Loading Capacity (Liquid)	3L	2L	4L	3L
Height Between Trays	70mm	100mm	50mm	70mm
Tray Temperature Difference	±1℃	±1℃	±1℃	±1℃
Refrigerant	R404A+R23	R404A+R23	R404A+R23	R404A+R23
Condenser Cooling Mode	Air cooling	Air cooling	Air cooling	Air cooling
Defrost Mode	Electric defrosting	Electric defrosting	Natural defrosting	Electric defrosting
Total Qty. of Vial	Φ12mm: 1554, Φ16mm: 868, Φ22mm: 440	Φ12mm: 2187, Φ16mm: 1200, Φ22mm: 654	Φ12mm: 2187, Φ16mm: 1200, Φ22mm: 654	Φ12mm: 3075, Φ16mm: 1554, Φ22mm: 2187
Vacuum Pump	4L/S (14.4m³/h)	6L/S (22m³/h)	6L/S (22m³/h)	6L/S (22m³/h)
Optional Accessories	Import vacuum pump, Vacuum pump anti-return valve, Oil mist filtration system, Vacuum adjustment device	Import vacuum pump, Vacuum pump anti-return valve, Oil mist filtration system, Vacuum adjustment device	Import vacuum pump, Vacuum pump anti-return valve, Oil mist filtration system, Vacuum adjustment device	Import vacuum pump, Vacuum pump anti-return valve, Oil mist filtration system, Vacuum adjustment device
Silicone Oil Heating Rods Consumption	600W	1000W	1600W	1600W
Total Consumption	3KW	4KW	4.5KW	5.5KW
Power Supply	AC220V, 50Hz/60Hz (single phase)	AC220V, 50Hz/60Hz (single phase)	AC220V, 50Hz/60Hz (single phase)	AC220V, 50Hz/60Hz (single phase)
Main Body Weight	300kg	400kg	300kg	400kg
External Size (WDH)	10337811580mm	10337811704mm	8259281366mm	85312771679mm
Packing Size (WDH) and Gross Weight	Main Body: 143310811880mm/330kg, Vacuum Pump: 770350450mm/65kg	Main Body: 143310812004mm/330kg, Vacuum Pump: 830370600mm/88kg	Main Body: 122512281666mm/430kg, Vacuum Pump: 785455300mm/95kg	Main Body: 122515771979mm/430kg, Vacuum Pump: 800500500mm/70kg
