Model No: SX25-UVAS-1600, SX25-UVAS-800
Features:
-
Man and Machine Coexistence: Can be used for disinfection in both manned and unmanned environments.
-
Shell Material: Made from metal with modern moisture-proof and rust-proof technology, featuring a sleek design with black acrylic panels.
-
Control Core: Utilizes a single-chip microcomputer with an LCD screen displaying indoor temperature and humidity in real time. It allows scheduling of 9 power on/off periods within 24 hours and offers three adjustable wind speed settings.
-
Working Modes: Includes automatic accumulation of working hours and offers four working modes: manual, scheduled, automatic, and temporary for user convenience.
-
Failure Alarms: Equipped with failure alarms for the ultraviolet lamp, fan, negative ion module, plasma module, filter, and UV lamp maintenance.
Features for ZY-Y-800:
-
Man-Machine Coexistence: Excellent purification and disinfection capacity.
-
Sterilization Technology: Utilizes quadruple sterilization disinfection technology, achieving a sterilization rate of 99.9%.
-
Primary Filter: Solid adsorption to remove small particles from the air.
-
Activated Carbon Filter: Adsorbs odors, formaldehyde, TVOCs, and other harmful gases.
-
UV Lamp: Effectively kills Staphylococcus albus and natural bacteria in the air.
-
Photocatalyst Filter: Under ultraviolet light, it degrades poisonous and harmful gases and kills various bacteria.
-
Negative Ion Generator (Optional): Releases high concentrations of negative ions to freshen the air.
Technical Parameters:
Model | SX25-UVAS-1600 | SX25-UVAS-800 |
Applicable Space | ≤160m3 | 20m3(Simulated field experiment with Staphylococcus albus)
30m3(Field experiments on natural bacteria in the air) |
Circulating Air | ≥1600m3/h | 800m3/h |
Shell Material | High quality cold rolled steel plate | |
Filter | Filter dust particles above 5μm | |
UV Lamp Life | ≥5000h | |
UV Leakage | ≤1μW/cm2 | |
O3 Leakage | ≤0.0125mg/m3 | ≤0.003mg/m3 |
Negative Ion Generation | ≥5*10^6pcs/cm3 | ≥3*10^6pcs/cm3 |
Natural Bacteria Extinction Rate | ≥90% | |
Sterilization Rate of Staphylococcus Albus | ≥99.9% | |
Noise | ≤55dB(A) | ≤48dB(A) |
Consumption | ≤270W | 230W |
Power Supply | Standard: AC220V, 50/60Hz
Optional: 110V, 50/60Hz(External transformer) |
Standard: AC220V, 50/60Hz
Optional: 110V, 50/60Hz |
External Size(W*D*H)mm | 370*360*1340 | 230*400*1040 |
Package Size(W*D*H)mm | 440*430*1420 | 295*440*1082 |
Net Weight(kg) | 39.8 | 28 |
Gross Weight(kg) | 45.7 | 30 |
