Model No: SX25-LFC-V-DDC, SX25-LFC-V-SDC-S
Features:
High-Quality Construction: Made of high-quality cold-rolled steel plate material with a welding structure and surface electrostatic spraying, enhancing the stability of the cabinet.
Efficient Pre-filtering: Equipped with a pre-filter that can preliminarily filter large particulate matter, improving the service life of the HEPA filter.
Durable Work Zone: The work zone is made of SUS304 stainless steel material, ensuring corrosion resistance and an aesthetically pleasing design.
Tempered Glass Windows: The front and side windows are made of 5mm thick tempered glass for durability and safety.
Integrated Base Stand and Casters: The base stand and casters are designed as an integrated unit, allowing for safe movement and leveling.
User-Friendly Touchscreen: A 7-inch color touch screen, password configurable, provides real-time display of running status (air velocity, pressure, timer, UV lamp time, HEPA filter running time, and the cabinet's operational state).
Timing Function: Equipped with an ultraviolet lamp and fan appointment timing function for easy scheduling.
Wind Speed Sensor: The wind speed sensor displays real-time wind speed, ensuring greater accuracy in air flow management.
Comprehensive Alarm System:
Ultra-high filter pressure alarm
Filter failure replacement alarm
Front window opening safety height alarm
Low wind speed alarm
Interlocking Functions: The cabinet features interlocking functions for:
UV lamp and front window
UV lamp and fan
Fluorescent lamp and fan
Fan and front window
Technical parameters:
| Technical Parameters | Model SX25-LFC-V-DDC | Model SX25-LFC-V-SDC-S |
|---|---|---|
| External Size (WDH) | 10606201850mm | 14606201850mm |
| Internal Size (WDH) | 935530650mm | 1335530650mm |
| Work Surface Height | 750mm | 750mm |
| Safety Height | 200~350mm | 200~350mm |
| Max Opening | 400mm | 400mm |
| Display | 7-inch color touch screen | 7-inch color touch screen |
| Airflow Velocity | 0.30~0.45m/s | 0.30~0.45m/s |
| Material | Working Area: 304 stainless steel, Main Body: 1.0mm cold-rolled steel with anti-bacteria powder coating | Working Area: 304 stainless steel, Main Body: 1.0mm cold-rolled steel with anti-bacteria powder coating |
| Front Window | 5mm toughened glass, anti-UV | 5mm toughened glass, anti-UV |
| Pre-filter | Polyester fiber | Polyester fiber |
| HEPA Filter | One, 99.995% efficiency at 0.3μm | One, 99.995% efficiency at 0.3μm |
| Front Window | Manual | Manual |
| Noise | ≤65dB(A) | ≤65dB(A) |
| Illumination | ≥300lx | ≥300lx |
| Vibration | ≤5μm(rms) | ≤5μm(rms) |
| Safety | Colonies Number≤0.5CFU/30min | Colonies Number≤0.5CFU/30min |
| Clean Level | ISO level 5(Class 100) | ISO level 5(Class 100) |
| Waterproof Sockets | Two sockets, Max. Power: 1000W | Two sockets, Max. Power: 1000W |
| Power Supply | AC220V±10%, 50/60Hz(Standard); 110V±10%, 60Hz(Optional) | AC220V±10%, 50/60Hz(Standard); 110V±10%, 60Hz(Optional) |
| Consumption | 1150W | 1250W |
| LED Lamp | 12W*1 | 16W*1 |
| UV Lamp | 20W*1 | 40W*1 |
| Standard Accessories | Base stand, LED lamp, UV lamp, Waterproof socket*2 | Base stand, LED lamp, UV lamp, Waterproof socket*2 |
| Package Size (WDH) | 12409001350mm | 16409001350mm |
| Gross Weight | 185kg | 231kg |
